Univer 500 F2K Fully refurbished Pertici double mitre saw

MACHINE FEATURES:

• Electronics double head cutting machine.
• Mobile head carriage automatic positioning.
• Magnetic rule length control system.
• Minimum cutting length 222 mm.
• Head angle range 90°/45°

BASIC COMPONENTS:

• 2 Carbide saw blades with a 500 mm. diameter
• Horizontal and vertical pneumatic clamping kit Integral pneumatic protection of cutting area.
• Additional horizontal clamping kit for side support with roller Side support with roller 3000 mm.

MACHINE CONTROL FEATURES:

• Machine cycle control with industrial computer, 3.5" floppy disk.
• Monochromatic LCD 5” display.
• Protected touch-sensitive keyboard.

SOFTWARE FUNCTIONS:

• Execute cuts with automatic correction of the profile height Store up to 100 values of profile height.
• Create and store 10 fixture typologies (stored on a floppy disk the number can be virtually infinite) using mathematical formulae which allow to calculate cutting lists with the setting of the external measurements of the fixture.
• Store and cut in automatic mode 4 cutting lists of 370 lines each typologies (stored on a floppy disk the number can be virtually infinite), which can be used through the development of the typologies or through the link with the office software.
• Sort out the cutting list according to the profile code and to the size of pieces.
• Software Easycut to execute the machine program on a office PC.
